Koop Mini Digger Engine (Euro 5) KD192FE
Description
Koop Mini Digger Engine (Euro 5) KD192FE
Koop Euro 5 Mini Digger Engine new
11.7 hp
8.6kw / 3600rpm
Displacement 0.499L
Note :- Can also be used to replace KD192F-1 (note also, the fuel pump and starter motor on the new engine will be different to the KD192F-1
| wer Type | Single cylinder, four-stroke, air-cooled, vertical |
| Combustion System | Direct Injection |
| Cylinder diameter*stroke (mm) | 92*75 |
| Displacement (L) | 0.499 |
| Compression ratio | 19.5 : 1 |
| Rated speed (rpm) | 3000 3600 |
| Rated power (kW) | 8.6 |
| Rated power (hp) | 11.7 |
| Start the system | F: Manual start / FE: Electric start |
| Fuel tank capacity (L) | 5.5 |
| Oil capacity (L) | 1.65 |
| Fuel consumption (g/kwh) | 275 280 |
| Fuel brand | Diesel: 0# (summer), -10# (winter) |
| Engine oil brand | SAE10W30 (CD grade and above) |
| Dimensions (mm) | 417*441*494 |
| Net weight (kg) | Hand start: 50/Electric start: 55 |
| Steering (viewed from flywheel) | Clockwise |
